Name: Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire
Brand: SMARTWEIGH INSTRUMENT CO.,LTD
SKU: Lastzelle MT1241-150kg 2m
Availability: InStock

Startseite Produkte

Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire

Produktdetails:

Herkunftsort:	CHINA
Markenname:	Mettler Toledo
Modellnummer:	Lastzelle MT1241-150kg 2m

Zahlung und Versand AGB:

Min Bestellmenge:	1 Satz
Preis:	Verhandlungsfähig
Verpackung Informationen:	Karonenschachtel
Lieferzeit:	10-30 Tage
Versorgungsmaterial-Fähigkeit:	2000 Stück pro Monat

Kontakt

Ausführliche Produkt-Beschreibung

Erzeugnis:	Mettler Toledo Wägezelle	Maximale Kapazität:	150 kg)
Material:	aus Aluminium, passiviert	Messtechnik:	NTEP III 5.000d OIML C3
Accuracy:	Standards	Schutzart:	IP67
Plattformgröße (LxB):	400 mm x 400 mm	Konnektivität:	Analog
Kabel:	6.6 ft (2 m)
Hervorheben:	MT1241 load cell sensor 150kg , industrial grade weighing sensor , load cell with 2m wire

Load Cell Sensor MT1241 150kg – Industrial Grade Weighing Sensor with 2m Wire

High-Performance Compression Weigh Module

This compression weigh module features top and base plates that compress under load, designed for direct installation on ground, piers, or structural beams. Ideal for large platform scales including truck and railroad track scales, as well as tank, hopper, and silo weighing applications.

Key Features

High-performance single point load cell with off-center compensation
Standard metrology approvals including OIML
Premium aluminum construction with strain gauge technology for durability
ATEX Zone 1/21/2/22 approvals included as standard
IP67 protection rating for harsh environments

Technical Specifications

Attribute	Value
Product	Mettler Toledo Load Cell
Maximum Capacity	330 lb (150 kg)
Material	Aluminum, passivated
Material Number	71201841
Metrology	NTEP III 5,000d OIML C3
Accuracy	Standard
Protection Rating	IP67
Platform Size (LxW)	400 mm x 400 mm
Connectivity	Analog
Cable	6.6 ft (2 m) PVC

Ideal Applications

Perfect for mid-size platform scales in industrial environments. The robust design and hazardous area certifications make it suitable for demanding weighing applications in manufacturing, logistics, and process industries.
